Verilog Code for I2C with RTL Schematic

Hi Guys,


Long time now. I was away dealing with my crappy life. Well, let's move to the main point as the title of this post suggests. This I2C is very much less complicated than all my previous I2C Verilog codes. The biggest surprise to my readers in this post is that this I2C has an RTL Schematic. I'll clear out everything about the code.



Let us begin.

I'll begin with the explanation of Master code first. I am assuming here that the readers have already read the I2C Basic post. If not then search this blog else move ahead.

In this I2C, I am assuming a few things.
1. It is a READ mode I2C only. No, Write mode. That would complicate a hell lot of stuff.
2. There is no malfunctioning with Master when it receives data from Slave, hence the acknowledge bit will be always 1(Not for Address matching).

What is in this I2C Code:
In this code, the master will send start bit and SCL will start. With this Master will start sending 7 bit Slave address. If the address does not match, it will restart i.e. keep on sending the same address. If the address matches, the Slave will send the acknowledgment. With acknowledgment, the Master will send the 8-bit register address.

Note: The code currently has no code to execute if register address matching fails. Might be updated later

After matching the register address, the Slave will send acknowledgment bit. After that, it will send the data associated with that register address. This will end with Stop bit.

Note: I still have some doubt on Start Bit and Stop bit.

To get the Master Code:
1. Disable Popups
2. Click Here to get the Master code
3. Click Here to get the Slave code

Master Code Description:

Line 1-4: I assume one knows what is this!!
Line 6: Register address from where data has to retrieve.
Line 7: SCL flag decides whether it is 1 or 0
Line 8: Slave_address of 7 bit. It contains the address of the Slave to be communicated.
Line 9: Start_Flag decides the start condition of I2C
Line 10: Status to signal the stop condition

Line 12: sda_val Value assigned to this will be sent through SDA line
Line 11: Direction chooses whether the signal is from or to.
Line 13:
Line 14: Contains slave address along with Read bit (hardcoded to 1)
Line 15: Count To count the clock
Line 16: Keep a Backup Copy of Slave Address
Line 17: Stores the Acknowledgement Bit
Line 18: Stores the data from Slave
Line 19: Used for START signaling
Line 20: Used for START signaling


Line 39-42: With falling SDA line checks if SCL is 1, then set A to 1
Line 46-50: If SDA is rising and SCL is 1 then set B to 1
Line 52: Set Start flag to ex-or of A and B
Line 54-58: With the rising clock, if start flag is 1, complement SCL(SCL clocking begins) else set SCL to1



Line 62-92: Check if SCL is 0 as SDA will only change when SCL is not changing. Then we will have to check the start flag. If it is set to 1, the transmission will begin. With first 8 counts, 7bit address and 1-bit read bit will be sent to Slave. SDA is of inout type which is a wire. This can only be used as a tri buffer. With count as 9, the direction will be set to 0 which sets the SDA line to 1'bZ. This will accept data from Slave now about the acknowledgment. For count as 10, we will set direction to 1
which means, Master will send data. The acknowledgment will be stored. If it is 1, which means the address is correct, we will send the register address from where we want data. If acknowledgment bit is 0, set count to 1 and retransmit the Slave address. This will keep on happening. When the count is 18, the direction is again changed to get the acknowledgment of register address. If 1, then proceed else NOTHING WILL HAPPEN as I HAVE NOT YET PUT A CODE WHICH WILL EXECUTE WHEN REGISTER ADDRESS FAILS.



Line 93-97: This will store the incoming data from Slave
Line 98-101: Acknowledgment informing the Slave about a successful transaction.
Line 102-105: Set SDA to 0 and status to 1
Line 108-110: If Status is 1, set SDA to 1.

Since SDA will always change when SCL is 0, Line 46-49 will never come true. However, we are deliberating setting SDA to 1 when SCL is 1 in Line 108-109. This will cause the code 46-49 to execute, which in turn set B to 1. Now with B set to 1, the start flag will be set to 0 in line 52. As the start flag is set to 0, Line 58 will execute which will set SCL permanently to 1. Thus I2C Connection closed.

RTL Schematic for RTL Lovers




For newbies, this is the hierarchy


Test.v is of Text Fixture type.
Master.v is Verilog File
Slave.v is Verilog File

Output (Slave Address Matched):



Output (Slave Address Mis-Matched):


Doubts?
Comment !!



Gate Primitives




Verilog Code for MOD 6 Counter




Verilog Code for MOD 5 Counter



Verilog Code for MOD Counters



Setup Time and Hold Time


Setup time and Hold time are very important concepts when designing circuits. Compromising with these parameters would give an organized output. Whenever we see a circuit, we see it switching instantly ON and instantly OFF. It just appears like teleportation. Electronics from the low state were teleported to a higher state and vice versa. However, teleportation never occurs in electronics. No matter how fast switching circuits has been invented, it will always take some amount of time.
Switching a circuit from LOW to HIGH does involve time. The time involved is as small as nanoseconds or picoseconds.



Setup Time:
The minimum time required to keep the input data stable while the clock has started to change is called Setup Time. Any change or malfunction of data within this period leads to Setup Violations.

Hold Time:
The minimum time required to keep the input data stable after the clock transition has taken place is called Hold Time. Any change or malfunction of data within this period leads to Hold Violations.


Below is the image how the human eye perceives a change in the clock signal



For the humans, it's always clear whether it is a HIGH or a LOW signal. However, the transition takes time. The delay introduced for the electronics to travel from a HIGH state to LOW takes place as shown in the below diagram.




The fall delay is the time taken for the transition from HIGH state to a LOW signal of any state. So when we see a clock working, we actually have a clock like this below.



To model these delays in Verilog, we use #NUMBER where NUMBER is the minimum number of clocks, the delay has to be made.

For example, if we make a simple code for AND gate, then the ideal gate would be coded as
and(C, A, B);   This represents C = A & B
However, with a delay in the circuit, we can code it as
and #1 (C, A, B): This too represents C = A & B but the output would have a delay of 1 tick of the clock.

Now each diagram above is a digital representation of a signal. What happens in the analog form is the most interesting part of signals. The analog form of the signal is the reason for Setup time and Hold time. When a signal is flipped to its complementary state, it takes time to stabilize. Until that time, the electronics oscillates in an undamped manner. This is called the switch Bouncing Effect. The following diagram would explain clearly.


Thus, the output clock edge must be captured and stabilized before any data change occurs. Now in Verilog, we use @posedge or @negedge for most sequential circuits. This means that the data has to undergo certain operations and produce an output during that change of transition, neither before, nor after. So the data is "held tightly" while the clock is transiting from the LOW state as we cannot afford the data to change before edge just because of some quantum disturbances. Now, as soon as the clock reaches midway, the change in data takes place and is again "held together" until the clock stabilizes its HIGH state.



As shown in the above diagram, during stabilization of clock, there are several "minute" positive and negative edge caused by oscillations which might trigger a change in the data if not held properly. It is this, why we require Setup Time and Hold Time.

To practice this in Verilog, we will execute some basic modules.

Code:
module Delay(A, B, C, D, E);
 input A,B;
 output C, D, E;
 wire p, q;


or #50 an2(q, A, B);
or #52 an3(p, A, B);
nand #54 an4(E, A, B);
assign C = p;
assign D = q;


endmodule

TestBench:
module TEst1;

reg A,B;
wire C,D,E;

Delay DEF(A, B, C, D,  E);

initial begin
A = 1;
B = 0;
end
endmodule

OUTPUT with the delay for all changes


Here is an easy example to explain Rise delay.


Code:
module Delay(A, B, C, D, E);
 input A,B;
 output C, D, E;
 wire p, q;


or #2 an2(C, A, B);
or an3(D, A, B);
endmodule

TestBench:
module TEst1;

reg A,B;
wire C,D,E;

Delay DEF(A, B, C, D,  E);

initial begin
A = 1;
B = 0;
        fork
       #10 A = 0; #B = 0;
end
endmodule

The signal D is driven without delay, hence it started the very moment, we started our simulation. It also changed its output when the inputs were changed at 10ns.
The signal C is driven by a delay of 2ns, hence it started with a delay of 2ns and also ended with a delay of 2ns. #NUM defines the delay where NUM is the delay of every parameter.

Now let us introduce, Rise delay and  Fall delay. Its basic syntax is:
#(R_Delay, F_Delay)

An example explaining both of these delay with comparison of no delay signal

Code:
module Delay(A, B, C, D, E);
 input A,B;
 output C, D, E;
 wire p, q;


or an2(q, A, B);
or #(2,0) an3(p, A, B);
or #(0,2) an4(E, A, B);

assign C = p;
assign D = q;
endmodule

TestBench:
module TEst1;

reg A,B;
wire C,D,E;

Delay DEF(A, B, C, D, E);

initial begin
A = 1;
B = 0;
fork
#10 A = 0;
#10 B = 0;
join
end
endmodule

Output:

Now as shown in the code, signal C has a Rise delay of 2ns but no fall delay, hence it started at 2ns and not at 0ns but ended exactly at 10ns as we changed the signal exactly at 10ns. Thus without Fall delay, we didn't see the delay in C when the inputs were changed. The signal D, as usual, is having no delay hence it started and stopped without any delay. Signal E has no Rise delay, hence it started without any delay but it does have Fall delay, hence it ended with a delay of 2ns.

In the case of Turn Off delay, it is the minimum amount of time required to jump from X, 0, 1 to a high impedance state Z. Z is called the high impedance state. It signifies a connection split, hence the output has a very high resistance and is floating. Similarly, x signal has an unknown signal state.

Now, every signal has 3 delays with 3 sub delay for each delay. Confused? Me too.
We have
1.)  Rise Delay 2.) Fall Delay 3.) Turn Off Delay
 Within the Rise/ fall/ turn-off delay, we have 3 subcategories.
  • Minimum Delay: This signifies the minimum amount of time delay to rise/ fall/ turn-off.
  • Typical Delay: This signifies the typical amount of time delay to rise/ fall/ turn-off.
  • Maximum Delay: This signifies the maximum amount of time delay to rise/ fall/ turn-off.
So now, we have to declare delay as follows:
#(min:typ:max, min:typ:max, min:typ:max)

Here is an example signifying the above:
Code:
module Delay(A, B, C, D, E);
 input A,B;
 output C, D, E;
 wire p, q;


or an2(q, A, B);
or #(0:2:4,2:3:4,1:2:3) an3(p, A, B);
or #(2:6:7) an4(E, A, B);

assign C = p;
assign D = q;
endmodule

TestBench:
module TEst1;

reg A,B;
wire C,D,E;

Delay DEF(A, B, C, D, E);

initial begin
A = 1;
B = 0;
fork
#10 A = 0;
#10 B = 0;
join
end
endmodule

Output:



Here signal C is having a typical Rise delay of 2ns and typical Fall delay of 3ns.

Verilog simulation in Xilinx


Hi
In this post, I am going to show you how to simulate a Verilog code in Xilinx ISE. I have included every step with an image so that the user can easily understand every step clearly.

Ok let's begin
I am using Xilinx ISE version 14.2
You can have your own version of Xilinx or ModelSim or MultiSim HDL Simulator but the methodologies for implementing a Verilog code within them might be different.

For this post its version 14.2


First of all click on the desktop icon ISE Design Suite 14.2



A Window will open. After the window opens, which might take some time depending on your system configuration. Click on the tab "New Project" as shown below.



Enter the name of the project in the first field. Be sure that the location where you are going to save your project is having permission to write. You cannot save at a location that has only read only permission.
Click "Next" and select the "Device" field as Spartan 6 because that's what I am going to use within this post.


Now click "Finish".

Now on the top left corner, you'll see two views. One of them states "Implementation" which is for finalizing implementing RTL schemaric of code and to find its parameters like heat, speeds, timings etc. The other view states "Simulation". We will start with the implementation first. Click on the  "Implementation" radio button

Under your project name you will see another folder structure named xclscf something like that. Right click and click on new source.


Select "Verilog Module" and give the module a name. Click next when done. You can leave the input and output ports blank or you can enter the ports if you are sure about your code. As I am never sure of my code, I will leave it blank. I'll insert the input and output ports within the code itself.


For this post, I am implementing my own SPI which is the serial peripheral interface in this simulation. To have a look on my SPI simulation and code, Click Here.

A window on the right side will pop out as shown below. It will have some predefined comments, describing the date, user and creator of project. It's just the time and owner stamp. It's upto you whether you want to keep it or not.


I removed the time and creator stamp and pasted my own Master code from my SPI post. I have also added Slave code using the same method as I showed above to add a new "Verilog Module". Now its time to explain in layman terms about module, testbench, and datapath. I am expecting all students to have some classes about Verilog coding and understanding of wires, outputs, and circuits.

Let us consider an IC which has components like register file, multiplexors, adder, subtractor etc as shown below.

As per the above diagram we have a component A and component B.
For each component, as shown above, for A and for B, will have to declare a module or specifically saying a Verilog module like below. For module A, we are having an input present at pin 2 and an output present at pin 7. Similarly, for module B we have an input from pin 3 and from A and a single output at pin 6. The Verilog code for the module or the component a using the description above will be as follows

module A(in_pin2, out_pin7, out_to_B);
input in_pin2,
output out_pin7,
output out_to_B;
initial begin
<Code>
end
endmodule

module B(in_pin3, in_from_A, out_pin6);
input in_pin3,
input in_from_A,
output out_pin6,
initial begin
<Code>
end
endmodule

This is how we are going to add Verilog code for master as well as the slave for our simulation.

No coming to the next question. What is a datapath?
Basically a data path includes the connection between various components inside the Integrated circuit. For example, in the above diagram, you can easily see components A and B are linked with each other using the red coloured wire and the wire which is attached to pin 7. Now, remember, for data path you have to include every wire that is connected between various models which are not present at the input or the output along with wires that you want to see as your output from the IC.

All the connection between various models which are not the input port or the output port have to be declared as wires. In the above diagram,  component A has two internal wires with  the component B, the first one is the red wire and the second wire is connected with pin 7. Now I want to see the input of component A and component B as well as the output of component A and component B.

module Datapath(in2,in3, out7, out6);
input int2, in3;
output out6, out7;
wire red_wire;
A Component_A(in2, out7, red_wire);
B Component_B(in3, red_wire, out6);
endmodule;

The basic syntax to instantiate a componet is

Component Name Variable_Name (PORTS IN ORDER)

Here component name is A. Its variable name is "Component_A" and ports which have to be in order as they were declared in A. Have a close look at the ports of componet A within the brackets.

(in_pin2, out_pin7, out_to_B);

The first port is in_pin2 which is an input pin attached to datapath port in2. The second port is out_pin7 which is connected to the out7 pin of the datapath. The third port is "out_to_B" which is an internal wire in datapath connected to "red_wire" in the datapath. One simply cannot assign any datapath port while instantiating a component. It has to be in order. Input port of IC is pin 2 which is declared as "in2" in the datapath. We have to connect this to component A's input which is "in_pin2" which is the first port declared within the brackets. Thus, while instantiating component A, we have to assign correct datapath port to the correct position of A. We cannot instantiate like this below

A Component_A(out7, in2, red_wire);

The first port of A, which is reserved to be input from pin 2 has to be the input from pin 2 but we have assigned "out7" to the input of A which is completely wrong. Similarly, we have assigned input from pin2 (in2) to the output of component A. The red wire is, however, assigned correctly to the 3rd position which points to output to B of A.


Now we have instantiated component A and component B within the data path, saving the data path module will automatically assign or basically put the module A and module B within the data path module. This shows that the models are being instantiated under the datapath module as shown in the below image. Now refer to the IC diagram above. As you can see, both the components lies within the IC. The IC is our datapath here hence, component A and B must lie within it.


Now coming to the tesbench part. A testbench is an environment which is used to provide input to our system and get the output from this system. Just take connecting a CRO to a transistor, where we can see the output from a transistor. Similarly, we can see our simulation through the testbench. One should always remember that all the input ports in the testbench have to be of Register type and all the outputs of have to be of wire type unlike in module where input has to be of wire type and the output can be wire as well as register.




To create a testbench, click on the "New source" and this time instead of selecting Verilog module select Verilog text fixture. It will show you some options of the available modules from your project on which you have to start your testing. We have to test the entire IC not specifically to the component A or component B. Select the data path module which is to be tested via Verilog text fixture or test bench. Xilinx will automatically assign ports according to the input and output ports defined in the data path module. Do remember that the internal wires are not attached with the testbench. The internal wire is that wire which is neither connected to the output nor to the input.
Only the input and the output of the data path will be connected to the test bench. All the input and output of the data path are the same to which we have to provide input and from which we have to derive the output.

To simulate, we have to select the view "Simulation' which was earlier set to "Implementation". The moment you will set it to "Simulation", in the below menu you will get options like this.


Double click on "Behavioral Check Syntax" to check the logic for errors. Wish for a green colored tickmark beside. If successful, double-click on "Simulate Behavioral Model" to simulate and wait for the results.


Now to see a specific port which is NOT present in the testbench can be selected from the leftmost panel from "Test" and "glbl" menu. Select the port and press CTRL + W and then "Re-Launch".

Regards

Neural Network: Part 2

Neural Network: Logistic Regression

In this post, I'll deal with logic regression and its implementation of a single neuron network. I hope you have read my previous post on mattresses and its operation using NumPy package. You can click here to go to my previous post

Logistic regression basically computes the probability of the output to be one. For example, if we train our Logistic model to recognize the image of a dog then for any new image the model basically try to calculate the probability of whether the new image is a dog or not. the higher the probability will imply that the given image is of a dog.

A neuron is the primary and fundamental unit of computation for any neural network. A neuron will receive a vector that will include the input features. Each of the features will get multiplied with their corresponding weights and then a bias will be added to each of the features after which the weighted sum will be calculated. This will produce a linear output from the previous step. After processing the linear output, data will have to pass through the activation function.

Activation Function

An activation function is a non-linear transformation which decides the probability of the linear input. Its output resides from 0 to 1 or from -1 to +1. This function helps in the mapping of values between a certain range which for us is between 0 and 1. For this post, I will use the Sigmoid function as the activation function. The Sigmoid function can be represented by the following equation
Sigmoid Function

The sigmoid function produces an S-shaped spanning across left and right plane. As per Wikipedia Sigmoid function is a bounded differentiable and a real function having a non-negative derivative at each.
Sigmoid Graph
Source: Wikipedia

Weights and Biases

Weights and biases are responsible to adjust the input function which consists of features in order to bring the final output close to the actual output. Weights are multiplied with the features and then the bias component is added. The output has been passed to the activation function. Recently added from StackOverflow an interesting thing about the bias. As the name suggests bias means to favour something irrespective of whether that thing is right or wrong. Similarly, the bias favors the actual output by adding itself to the weighted sum.


The output z will now act as an input to our sigmoid function. One thing that users must always remember is that weight is a column vector whose size is equal to the number of features in the input and bias is a scalar number. The sigmoid function will now map the value of Z between 0 and 1. The output from this sigmoid function will indicate the probability of how close the input is to the actual output.

Clearly, the above example was for a single input sample. What if we have multiple input samples? Well, the Logistic regression also works on multiple training samples. Suppose there are m training samples and each of the samples has n features then the input can be stated as M x N matrix. Let us call this matrix as X. Now we can easily perform dot product between X and the weight vector to get a linear output. The vector output will be then passed to the activation function which will result in an output vector A containing the probabilities of each training sample.


In the next post, I'll deal with the Loss function, Cost function and the implmentation of SNN (Single Neuron Network).

Neural Network: Part 1


Basics of Neurons


Hey everyone, long time no see. I have been working on some stuff so was busy and away from my blog. Well, as for my interest in AI, I have been working on neural networks and its implementation which I'll discuss in this post.

In this post, you will learn:
  • The basic concepts used in building a neural network
  • Implementing logistic regression
  • Single Neural Network
  • Forward propagation and Backward propagation
  • Building a small neural network using TensorFlow
  • Building a deep neural network using TensorFlow.
As we know, we humans learn from our experiences and through training. Our brain runs a very high speed and processes any activity quickly. Well, it actually depends on the type of activity, the person is working on. But as we all know, humans have a high grasping power and easily learn, understand, classify, remember and do various other things which machines take a hell lot of time to compute. All these computations are processed by our mighty brain. So to understand the technical neural network, we must understand the biological neural network.

Source: Wikipedia


The brain consists of a huge number of neurons. These neurons are the fundamental unit of the brain. They receive electric signals as input from the external world (Hello World!!) which are processed and sent to other neurons. A basic neuron consists of axion, dendrites, action potential, synapse etc.


Axons are the thin structure and are called as the transmitting part of the neurons. Dendrite is the receiving part of the neuron which receives its input from synapse summing total inputs. The action potential helps the neurons to communicate with each other. So basically, neurons receive electrical impulses from dendrites, which informs the neuron about the outcome of an incident. If the outcome is not in favor, these impulses are altered by chemical and electrical reactions and sent to other neurons by neurotransmission. This keeps on happening until the brain achieves perfection.

In a similar way, we will work on an Artificial neuron.
Matrices and its manipulation is a basic requirement for this post. To simplify, we will work on the dot product, vectors, and broadcasting in python.

Dot Product
  If A is a C × D matrix and B is a D × E matrix, then the dot product of A and B is a C × E matrix. The dot product will reduce our computation time whenever we have quite a lot of equations. Note that the number of columns in the first matrix should always be equal to the number of rows in the second matrix. In python, we will use dot() function from the NumPy package.

A typical example describing the dot() function in the NumPy package

   import numpy as np
   a = np.array([[7,6],[2,5]])
   b = np.array([[10,6,70],[18,9, 11]])
   c = np.dot(a,b)
   print("Shape of A ", a.shape)
   print("Shape of B ", b.shape)
   print("Shape of C ", c.shape)
   print("The dot product of A and B is : ", c)

And the result is

Broadcasting
   Broadcasting in Python helps to perform element-wise calculation between a matrix and vector or scalar. Scalar is the just a single number whereas a vector is rank 1 array. The advantage of NumPy package is that it provides all these operations on matrices, vectors, reshaping, transform etc.A vector can be represented as numpy.ndarray(n-Dimensional Array) object using NumPy's array() function. A column vector is of shape (A × 1) and a row vector is of shape (1 × B)

To shape an array we use the syntax Array_name.reshape(row, column)
To find the rank of the matrix we will use the function numpy.linalg.matrix_rank()

These were the basics required to start a simple program or project on neural networks. In the next post, I'll deal with Logic Regression with a single neuron which requires the basics as I have described above.

Update: Click here to jump to my next post





SARSA Learning with Python

Hola,
I worked on SARSA algorithm as well as on Q Learning algorithm and both of them had different Q matrix (Duh!) The methodology of both of the algorithms depicts how well one algorithm responds to future awards (which we can say OFF Policy for Q learning) while the other works of the current policy and takes an action before updating Q matrix (ON Policy).

The previous post example of the grid game showed different results when I implemented SARSA. It also involved some repetitive paths whereas Q didn't show any. A single step showed that SARSA followed the agent path and Q followed an optimal agent path.

To implement both ways I remember the way of pseudo code.

QL

initiate Q matrix.
Loop (Episodes):
   Choose an initial state (s)
   while (goal):
   Choose an action (a) with the maximum Q value
   Determine the next State (s')
   Find total reward -> Immediate Reward + Discounted Reward (Max(Q[s'][a]))
   Update Q matrix
   s <- s'
new episode

SARSA-L

initiate Q matrix
Loop (Episodes):
   choose an initial state (s)
   while (goal):
   Take an action (a) and get next state (s')
   Get a' from s'
   Total Reward -> Immediate reward + Gamma * next Q value - current Q value
   Update Q
   s <- s' a <- a'

Here are the outputs from Q-L and SARSA-L


The above is Q-L


This one is SARSA

There is a difference between both Q Matrix. I worked on another example by using both Q learning and SARSA. It might appear similar to mouse cliff problem for some readers so bear with me.


The code for Naruto-Q-Learning is below






Here is Hinata trying to find her way to her goal by using SARSA




The code for Hinata SARSA Learning

I used epsilon-greedy method for action prediction. I generated a random floating number between 0 to 1 and set epsilon as 0.2. If the generated number is greater than 0.2 then I select maximum Q valued action (argmax). If the generated number is less than 0.2 then I select the action (permitted)  randomly. With each episode passing by, I decreased the value of epsilon (Epsilon Decay) This will ensure that as the agent learns its way it follows the path rather than continuing exploration. Exploration is maximum at the start of the simulation and gradually decreases as each episode are passed.


This is the decay of the epsilon.

The path followed in the above simulation is 0 - 4 - 8 - 9 - 10 - 11 - 7. Sometimes the agent also follows the same path as followed during Q learning. Well, I am continuing my exploration for the same and will post more details as I learn more about RL.

Till then, bye

Q-Learning with Python

Hola,
Currently, I am working on learning algorithms in Data Science for robotics. Reading many examples online and trying them on my own gives me a feeling of reward. I got deeply fascinated by Q learning algorithm based on the Bellmans equation. I also made a Pong game using Q learning. You can view that project on my instructable.

It didn' take much time to understand the working of Q learning. It appeared similar to the State Space matrix that I studied in my Control Systems class in college which I have forgotten now. However, seeing a practical application makes it easier to learn.

Q-Learning is based on State-Action-Reward strategy. For example, every state has various actions that can be implemented in that state and we have to choose the action which returns maximum rewards for us.

The agent will roam around like a maniac at the start and learn about its actions and rewards. The next time when the agent faces the similar state, it will know what to do in order to minimize the loss and maximize the reward.

The basic equation of Q learning algorithm is

Q(s,a) = Q(s,a) + X*(R(s,a) +  Y * (Max(s',a)) - Q(s,a))

This algorithm follows Off Policy algorithm. The Q value is revised using the next state S' and next action A' based on next state. It basically increases its probability or Q value by adding a discounted reward from the next state that is yet to happen. I guess this is the reason why many other fellows also call it sometimes "greedy".

Here Q is the Q Matrix or better say the brain of our agent. R is the reward matrix which stores the reward for every step taken i.e. reward returned from a taken action in the particular state.

s' is the next state after the action is taken.
X is the learning rate. Closer to 1 means doing no mistakes at all which is superficial. Closer to 0 means no learning at all which we don't want at all.
Y is the discount factor. It tells the agent how much far it has to look. It can be understood with an example. The more importance you give to future rewards, the more will be the discount factor. The more you value near rewards, the less is the discount factor.

0 <= X,Y <= 1

I began with a 4 X 4 matrix like this


The green square is the goal with reward 100. The red square is danger and the agent has to avoid or else -10 reward rest all squares can be used for locomotion with a reward of -1.

I assigned each square with a state number. The actions of the agent will be 0, 1, 2, 3 where 0 is for UP, 1 is for DOWN, 2 is for LEFT, 3 is for RIGHT

This is my reward matrix
reward = np.array([[0, -10, 0, -1],
                   [0, -1, -10, -1],
                   [0, -1, -1, 10],
                   [0, -10, -1, -1],

                   [-10, -1, 0, -1],
                   [-1, -1, -10, -1],
                   [1, -10, -1, -10],
                   [100, -1, -1, 0],

                   [-10, -1, 0, -1],
                   [-1, -1, -1, -10],
                   [-1, -1, -1, -1],
                   [-10, -1, -10, 0],

                   [-1, 0, 0, -1],
                   [-1, 0, -1, -1],
                   [-10, 0, -1, -1],
                   [-1, 0, -1, 0]])

Each row is the state and each column is the action taken in that state. The value indicated is the reward for a particular action in a particular state. Here 0 means invalid reward i.e. that action si not valid. We cannot go UP or LEFT from state 0. Thus for state 0 reward matrix will be [0, -10, 0, -1]. The blueprint is [UP, DOWN, LEFT, RIGHT] so if we jump UP from state 0 it is not possible thus reward is 0. If we jump DOWN we land to red square thus reward is -10. If we move RIGHT we get -1 as our reward. Thus the reward matrix has a total of 16 states where each state has 4 actions.

The next state matrix is this

n_s = np.array([[-1,4,-1,1],
               [-1,5,0,2],
               [-1,6,1,3],
               [-1,7,2,-1],

               [0,8,-1,5],
               [1,9,4,6],
               [2,10,5,7],
               [3,11,6,-1],

               [4,12,-1,9],
               [5,13,8,10],
               [6,14,9,11],
               [7,15,10,-1],

               [8,-1,-1,13],
               [9,-1,12,14],
               [10,-1,13,15],
               [11,-1,14,-1]])

We have 16 states with 4 actions and each value represents the next state when an action is taken. Here -1 represents invalid state i.e. not possible.

The Action matrix is like this
action = np.array([[0,3],
                  [1, 2, 3],
                  [1, 2, 3],  "State 2 can have DOWN, LEFT, RIGHT"
                  [1, 2],

                  [0,1,3],
                   [0,1,2,3],
                   [0,1,2,3],
                   [0,1,2],

                   [0,1,3],
                   [0,1,2,3],
                   [0,1,2,3],
                   [0,1,2],

                   [0,3],
                   [0,2,3],  "State 13 can have DOWN, LEFT, RIGHT"
                   [0,2,3],
                   [0,2]])

Q matrix is initialized as 16 X 4 matrix (16 states and 4 actions)
Q matrix stores the experience rewards. For example, Q[12][3] will represent the experience of when the agent was in state 12 and his action is 3 (LEFT). I understand this concept with probability. Greater is the value, greater is the probability of higher reward.

Here i_state represents the initial state of the agent which is 11.
i_s = np.array([[1,2,5,6,8,9,11,12,13,14,15]])
This is an array that stores the states from where agent can begin his training.

I began with 10 episodes as it was enough for my agent to learn. The loop begins with choosing a random state from i_s matrix at line 77.  Our goal is state 3 thus we run the agent until he reaches his goal. Line 81 describes the for loop which finds the maximum Q value (probability) among all possible actions in that state. Line 85: We find the next state based on the action taken. Line 89: We find maximum Q value of all possible actions of the next state. Line 93: We use the Q-Algorithm equation to find the value of that particular Q matrix location. Line94: All movements of the agent is recorded inside this matrix. Line 95: The next state becomes the current state. When the goal is met a new episode is started.

Let the starting position of the agent be 11. Thus now we apply the policy in this state. The possible actions in state 11 are TOP, LEFT, DOWN.
 Let Q[11] be [1, 3, 2, 5]
for i in action[i_state]:
if Q[i_state][i]>Qx:
act = i
Qx = Q[i_state][i]
n_state = n_s[i_state][act]
action[11] is [0, 1, 3]
Thus if Q[11][0] > Qx(-999) then act will be 0
Qx will be updated. When this loops runs act will be 3 because the maximum value among Q[11][0] = 1, Q[11][1] = 3, Q[11][3] = 5 is 5 which has index 3 thus it means the action that will reward maximum Q value in state 11 is 3.
 With this action value we can get out next state and that will be 10 i.e. the agent moves LEFT.

for i in action[n_state]:
nxt_values.append(Q[n_state][i])
Max = max(nxt_values)

Now we have the next state as 10. Now we will calculate the maximum Q value is that state for all possible actions and store it in Max.
 Multiplying this value (Max) with discount factor gives the future reward which we add with the immediate reward. The immediate reward is calculated with R matrix. The sum of immediate reward and the discounted reward is multiplied by the learning rate and added with Q value at that state: action location.


Each episode has a total reward as calculated at Line 92.
The xd matrix is [11, 15, 14, 13, 9, 5, 6, 2, 3]. This is the optimal pathway of the agent to reach the goal.


So Long

EDIT: There was an error in the action matrix. It has been corrected
